Before switching on the hydraulic unit:
• Check the electric wiring.
• Check the refrigeration circuit and make sure the gas
supply has been performed.
• Check the pressure of the hydraulic circuit (1-2 bar),
check that the heat pump is purged, and the rest of the
installation.
• Make sure that ALL DIPSW on the interface card are
OFF before starting up.
13.1 Start-up check-list
13.1.1 Before starting-up
• Sight checks
Outdoor unit (see chapiter "Installation of the outdoor unit", page 15). OK Non compliant
Location and ttings, condensate evacuation.
Compliance with distances from obstacles.
• Hydraulic checks
Hydraulic unit (see chapiter "Installing the hydraulic unit", page 18). OK Non compliant Value
Connection of pipes, valves and pumps (1 or 2 circuits, DHW).
Installation water volume (expansion vessel of adequate capacity ?).
No leaks.
Main system pressure and degassing.
• Refrigeration connections and checks
(see chapiters "Refrigerant gas connection
and lling the installation with gas", page 19 & "Filling the installation with gas", page 24).
OK Non compliant
Refrigerant circuits control (Sealing respected, no dust and moisture).
Connections between units (pipe length, are tightening torque...).
Installation of HP, LP pressure switches on "Gas" line (large pipe).
Pump down required.
Nitrogen leak test (~ 10 bar).
Opening of refrigeration valves to outdoor unit.
Refrigerant lling of hydraulic unit and pipes.
• Electrical checks
Outdoor unit (see chapiter "Electrical connections", page 36). OK Non compliant Value
Main power supply 230 V.
Protection by rated circuit breaker.
Cable cross-section.
Earth connection.
Hydraulic unit (see chapiter "Electrical connections
on the hydraulic unit side", page 40).
OK Non compliant
Connection with outdoor unit (phase, neutral, earth).
Sensors connection (positioning and connections).
3 way valve and circulators connections.
Power supply and protection of electric auxiliary.
13 Quick-start procedure
Installation and operation manual "1734 - EN"
Heat pump air/water split 1 service alféa extensa +
- 80 -
