Installation and operation manual "1734 - EN" - 85 -
Heat pump air/water split 1 service alféa extensa +
Trade name / Models : atlantic / Alféa ... extensa + 5 extensa + 6 extensa + 8 extensa + 10
Reference 522 220 522 221 522 222 522 225
Heating ranges 35°C 55°C 35°C 55°C 35°C 55°C 35°C 55°C
Declared coefcient of performance or primary energy ratio for part load at indoor temperature 20°C and outdoor temperature Tj
Tj = -7°C COP
d
- 2.86 1.86 2.65 1.79 2.35 1.77 2.35 1.74
Tj = +2°C COP
d
- 4.10 2.82 4.17 2.86 3.82 2.93 3.81 2.74
Tj = +7°C COP
d
- 5.00 4.00 5.99 4.03 5.69 4.12 5.71 4.10
Tj = +12°C COP
d
- 8.12 5.84 8.29 5.84 8.16 5.81 7.16 5.72
Tj = bivalent temperature COP
d
- 2.86 1.86 2.65 1.79 2.35 1.77 2.35 1.74
Tj = operation limit temperature COP
d
- 2.65 1.54 2.57 1.56 2.02 1.47 2.16 1.44
For Air-to-water heat pump: Operation limit
temperature
TOL °C -10 -10 -10 -10 -10 -10 -10 -10
Heating water operating limit temperature WTOL °C 55 55 55 55 55 55 55 55
Supplementary heater
Rated heat output
(2)
P
sup
kW 0.6 1.1 0.7 1.0 0.9 1.2 1.4 1.7
Type of energy input - - Electricity
Power consumption in modes other than active mode
Off mode P
OFF
W 6 6 6 6 6 6 5 5
Thermostat-off mode P
TO
W 19 17 23 16 30 16 43 22
Standby mode P
SB
W 10 10 10 10 9 9 8 8
Crankcase heater mode P
CK
W 0 0 0 0 0 0 0 0
Other items
Capacity control
- - Inverter
For Air-to-water heat pump, rated air ow rate
- m
3
/h 2070 2340 3600 6200
(1) Seasonal efciency calculation is detailed in package che - room units are available as option and includes: thermostat and room sensors, room unit controller wether
they are, or not, integrated in kits.
(2) For heat pump space heaters and heat pump combination heaters, the rated heat output P
rated
is equal to the design load for heating P
designh
, and the rated heat output
of the supplementary heater P
sup
is equal to the supplementary capacity for heating sup(Tj).
(3)
If Cdh is not determinated by measurement then the default degradation coefcient is Cdh=0.9.
