To measure the pulse frequency use a static torque transducer or an inline transducer connected to
torque testing equipment, see Tool condition test.
Oil filling and changing instruction for Pulse unit
Required equipment for oil filling and oil changing:
■
Atlas Copco Pulse unit oil, for Ordering Number see Spare parts list.
■
Pulse unit Oil filling kit, for Ordering Number see Spare parts list.
Oil filling kit contains:
■
2 x Adapter M3
■
2 x Adapter M4
■
4 x Hose length 540 mm
■
2 x Hose length 50 mm
■
1 x Hose length 120 mm
■
1 x Syringe 50 ml
■
1 x Syringe 1 ml
■
4 x Plug
■
5 x Connection
■
2 x Connection
■
2 x Can
■
2 x Cover
1. Place the Pulse unit in a vise at an angle so that the outlet hole is at the highest point.
2. Remove the screw covering the inlet opening. Make sure that the o-ring is on the screw and not left
in the Pulse unit. Attach the filling hose by hand, with the hose connector end to the Pulse unit.
3. Fill the large syringe with oil to maximum capacity from the oil can.
Always use new Atlas Copco Pulse unit oil.
4. Remove the stop plug from the filling hose and then attach the syringe to the hose.
5. Remove the screw covering the outlet opening of the Pulse unit. Make sure that the o-ring is on the
screw and not left in the Pulse unit. Attach the return hose to the Pulse unit.
6. Remove the stop plug from the return hose and then attach it to the oil can.
7. Start filling oil into the Pulse unit from the large syringe. When filling oil into the Pulse unit, there will
be air bubbles exiting.
8. Jiggle the anvil back and forth until there are no more bubbles, to make sure that all air is gone from
the Pulse unit, while filling the oil.
9. Remove the return hose from the oil can and attach the stop plug to the return hose end.
10. Remove the return hose from the outlet opening of the Pulse unit. Put the screw covering the outlet
opening back in position.
11. Now position the Pulse unit horizontally in the vise with the inlet opening facing upwards.
12. Remove the syringe from the filling hose and attach the stop plug to the filling hose.
13. Remove the oil filling hose from the Pulse unit.
14. Use the small syringe to extract the right amount of oil accordingly, see table Oil filling .
15. Put the screw covering the inlet opening back in position.
Oil filling
Oil reduction (X) from 100% full Pulse unit Approximate oil volume in Pulse unit
± 0.05 ml 6 ml
