Page #6 background imageLoading...
Page #6 background image
Product information EN EP5PTI19 HR10-MT
6
© Atlas Copco Industrial Technique AB - 9839 0661 01
Technical data
Ordering No 8431038130
Model EP5PTI19 HR10-MT
Model type Pistol
Shut-off Yes
Air consumption under load cfm 14 cfm
Air consumption under load l/s 6.5 l/s
Air inlet thread in 1/4 in
Bolt size mm M6 mm
CS distance mm 23 mm
EC directives 2006/42/EC
EC standard EN ISO 11148-6:2012
Free speed r/min 7300 r/min
Length mm 168 mm
Max working pressure bar 7 bar
Max working pressure psi 100 psi
Recommended hose size mm 8 mm
Sound pressure dB(A) 76 dB(A)
Sound standard ISO15744
Sound uncertainty dB(A) 3 dB(A)
Square drive in 3/8 in
Torque range max Nm 19 Nm
Torque range max ft lb 14 ft lb
Torque range min Nm 8 Nm
Torque range min ft lb 6 ft lb
Vibration standard ISO28927-2
Vibration value m/s² 1.7 m/s²
Weight 0.9 kg
Weight 2.0 lb
