EP5PTI19 HR10-MT EN Installation
© Atlas Copco Industrial Technique AB - 9839 0661 01
7
Installation
Installation requirements
Air quality
For optimum performance and maximum product life we recommend the use of compressed air with
a maximum dew point of +10°C (50°F). We also recommend to install an Atlas Copco refrigeration
type air dryer.
Use a separate air filter which removes solid particles larger than 30 microns and more than 90% of
liquid water. Install the filter as close as possible to the product and prior to any other air preparation
units to avoid pressure drop.
For impulse/impact tools make sure to use lubricators adjusted for these tools. Regular lubricators
will add too much oil and therefore decrease the tool performance due to too much oil in the motor.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Both lubricated and lubrication free products will benefit from a small quantity of oil supplied from a
lubricator.
Air lubrication guide
Brand Air lubrication
Atlas Copco Optimizer (1 liter) 9090 0000 04
Q8 Chopin 46
Shell Shell Air Tool Oil S2 A 320
Compressed air connection
WARNING Compressed air can cause serious injury
Always shut off the air supply, drain hose of air pressure and disconnect the tool from air supply;
when not in use, before making any adjustments to the product - for example changing acces-
sories, or when making repairs.
WARNING Whipping hoses can cause serious injury
Always make sure that there are no damaged or loose hoses or fittings.
WARNING Compressed Air
High air pressure can cause severe damage and bodily injury.
Do not exceed maximum air pressure.
Make sure that there are no damaged or loose hoses or fittings.
For correct air pressure and hose size, see section Technical data.
Make sure that the hose and couplings are clean and free from dust before connecting to the tool.
Installation instructions
Installation of vibrating tools
We recommend using a minimum length of 300 mm (12") of flexible hose for compressed air between a vi-
brating tool and the quick-action coupling.
