- 9 -
Operating manual SUNTEST XLS / XLS+
2
Installation of equipment
2.3 Location requirements
Climatic conditions required for the place of installa-
tion:
• During continuous operation, the hot air emitted by
the air-cooling system results in a constantly chan-
ging climate in the room. Therefore, the SUNTEST
equipment should only be installed in air-conditioned,
sufficiently ventilated places of installation.
• The places of installation must be kept free of dust.
• The room temperature must be maintained between
18°C and 25°C.
• The max. relative humidity should be 70%.
The requirement for coolant air is as follows:
• Lamp cooling 250 m³/h,
• Air conditioner for the test chamber 340 m³/h.
Installation:
• Dimensions of equipment (width x depth x height):
930 mm x 500 mm x 485 mm,
• Weight of equipment approx. 80 kg,
• The equipment must be set up on a sufficiently stable
laboratory bench with a non-flammable support un-
derneath and the laboratory bench should be aligned
so that it is horizontal.
• Please lift the unit for any displacement to avoid that
the rubber feet fall off the fixing screws.
Caution - Overheating of the equipment:
Blocking of the air inlet and air outlets can result in
overheating and damage to the equipment!
When installing the equipment, the following mini-
mum distances to the neighboring walls or objects
must be maintained:
to the front 700 mm
to the back 500 mm
to both sides 300 mm
on top 400 mm.
