394

7679H–CAN–08/08

AT90CAN32/64/128

Figure 28-20. I/O Pin Source Current vs. Output Voltage (Vcc = 2.7V)

Figure 28-21. I/O Pin Sink Current vs. Output Voltage (Vcc = 5V)

I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE (Vcc = 2.7V)

-30

-25

-20

-15

-10

-5

0.5 1 1.5 2 2.5 3

(V)

(mA)

85°C

25°C

-40°C

I/O PIN SINK CURRENT vs. OUTPUT VOLTAGE (Vcc = 5V)

0 0.5 1 1.5 2 2.5

(V)

(mA)

85°C

25°C

-40°C
