Atmel XMEGA A3 series User Manual

27
8068C–AVR–06/08
XMEGA A3
14.3.1 Push-pull
Figure 14-1. I/O configuration - Totem-pole
14.3.2 Pull-down
Figure 14-2. I/O configuration - Totem-pole with pull-down (on input)
14.3.3 Pull-up
Figure 14-3. I/O configuration - Totem-pole with pull-up (on input)
14.3.4 Bus-keeper
The bus-keeper’s weak output produces the same logical level as the last output level. It acts as
a pull-up if the last level was ‘1’, and pull-down if the last level was ‘0’.
INn
OUTn
DIRn
Pn
INn
OUTn
DIRn
Pn
INn
OUTn
DIRn
Pn
