66
8068C–AVR–06/08
XMEGA A3
36. Datasheet Revision History
36.1 8068C – 06/08
36.2 8068B – 06/08
36.3 8068A – 02/08
1. Updated ”Features” on page 1.
2. Updated Figure 2-1 on page 2.
3. Updated ”Overview” on page 3.
4. Updated Table 7-2 on page 13.
5. Replaced Figure 24-1 on page 41 by a correct one.
6. Updated “Features” and ”Overview” on page 42.
7. Updated all tables in section ”Alternate Pin Functions” on page 50.
1. Updated ”Features” on page 1.
2. Updated ”Pinout/Block Diagram” on page 2 and ”Pinout and Pin Functions” on page 48.
3. Updated ”Ordering Information” on page 2.
4. Updated ”Overview” on page 3, included the XMEGA A3 explanation text on page 6.
5. Added XMEGA A3 Block Diagram, Figure 3-1 on page 4.
6. Updated AVR CPU ”Overview” on page 6 and Updated Figure 6-1 on page 6.
7. Updated Event System block diagram, Figure 9-1 on page 16.
8. Updated ”PMIC - Programmable Multi-level Interrupt Controller” on page 24.
9. Updated ”AC - Analog Comparator” on page 43.
10. Updated ”I/O configuration” on page 26.
11. Inserted a new Figure 15-1 on page 31.
12. Updated ”Peripheral Module Address Map” on page 53.
13. Inserted ”Instruction Set Summary” on page 54.
14. Added Speed grades in ”Speed” on page 59.
1. Initial revision.
