Page #47 background image
47
8068C–AVR–06/08
XMEGA A3
28. Program and Debug Interfaces
28.1 Features
PDI - Program and Debug Interface (Atmel proprietary 2-pin interface)
JTAG Interface (IEEE std. 1149.1 compliant)
Boundary-scan capabilities according to the IEEE Std. 1149.1 (JTAG)
Access to the OCD system
Programming of Flash, EEPROM, Fuses and Lock Bits
28.2 Overview
The programming and debug facilities are accessed through the JTAG and PDI physical inter-
faces. The PDI physical uses one dedicated pin together with the Reset pin, and no general
purpose pins are used. JTAG uses four general purpose pins on PORTB.
28.3 JTAG interface
The JTAG physical layer handles the basic low-level serial communication over four I/O lines
named TMS, TCK, TDI, and TDO. It complies to the IEEE Std. 1149.1 for test access port and
boundary scan.
28.4 PDI - Program and Debug Interface
The PDI is an Atmel proprietary protocol for communication between the microcontroller and
Atmel’s development tools.
