XMEGA A3
Figure 26-1. Analog comparator overview
AC0
+
-
Pin inputs
Internal inputs
Pin inputs
Internal inputs
VCC scaled
Interrupt
sensitivity
control
Interrupts
AC1
+
-
Pin inputs
Internal inputs
Pin inputs
Internal inputs
VCC scaled
Events
Pin 0 output
