51
8068C–AVR–06/08
XMEGA A3
Table 29-3. Port C - Alternate functions
PORT C PIN # INTERRUPT TCC0 AWEXC TCC1 USARTC0 USARTC1 SPIC TWIC CLOCKOUT EVENTOUT
PC0 16 SYNC OC0A OC0A SDA
PC1 17 SYNC OC0B OC0A XCK0 SCL
PC2 18 SYNC/ASYNC OC0C OC0B RXD0
PC3 19 SYNC OC0D OC0B TXD0
PC4 20 SYNC OC0C OC1A SS
PC5 21 SYNC OC0C OC1B XCK1 MOSI
PC6 22 SYNC OC0D RXD1 MISO
PC7 23 SYNC OC0D TXD1 SCK CLKOUT EVOUT
GND 24
VCC 25
Table 29-4. Port D - Alternate functions
PORT D PIN # INTERRUPT TCD0 TCD1 USARTD0 USARTD1 SPID CLOCKOUT EVENTOUT
PD0 26 SYNC OC0A
PD1 27 SYNC OC0B XCK0
PD2 28 SYNC/ASYNC OC0C RXD0
PD3 29 SYNC OC0D TXD0
PD4 30 SYNC OC1A SS
PD5 31 SYNC OC1B XCK1 MOSI
PD6 32 SYNC RXD1 MISO
PD7 33 SYNC TXD1 SCK CLKOUT EVOUT
GND 34
VCC 35
Table 29-5. Port E - Alternate functions
PORT E PIN # INTERRUPT TCE0 TCE1 USARTE0 USARTE1 SPIE TWIE CLOCKOUT EVENTOUT TOSC
PE0 36 SYNC OC0A SDA
PE1 37 SYNC OC0B XCK0 SCL
PE2 38 SYNC/ASYNC OC0C RXD0
PE3 39 SYNC OC0D TXD0
PE4 40 SYNC OC1A SS
PE5 41 SYNC OC1B XCK1 MOSI
PE6 42 SYNC RXD1 MISO TOSC1
PE7 43 SYNC TXD1 SCK CLKOUT EVOUT TOSC1
GND 44
VCC 45
