6.0 Operation Receptal
®
6.2 Assembling the Receptal
®
secretion canister system
Insert the Receptal
®
bag into the Receptal
®
canister.
Close the canister tightly at all sides.
Check again for density, otherwise no vacuum can
be built up.
Insert the vacuum hose.
Onlybagswithintegratedbacterialltermaybeused!
Fig 12.
Fig. 13.
● Onlyusesecretionbagswithintegrated
bacteriallter!
 Abacteriallteravoidsdivulgementof
bacterias.
● Sterilepackedpartsmaynolongerbe
used if their packing was damaged during
transport or storage
Danger of infection for the patient.
6.1 Holder for Receptal
®
secretion
canister
Plug the screw thread of the holder from the top into the
borehole at the bottom side of the device.
Screw it together with the provided screw nut.
Fig. 11.
Receptal
®
bag
Receptal
®
canister
11
Vacuum channel
12
Vacuum hose
13
Connection for vacuum hose
Thesecretionissuckedo󰀨throughthevacuum
channel.
6.3 Connect hose
!

!
i
11 12 13
