9. Auxilia Positioning
9.1 Notes:
9.1.1 Auxilia positioning can only be calibrated through the oine display screen or APP. It can only be used on the PC and
cannot be calibrated. For precise positioning, calibration must be peormed through the display screen/APP rst.
9.1.2 If the machine is not moved or the laser module is not disassembled, there is no need to repeat the positioning. If the laser
module is disassembled or the machine is moved, repositioning is required for accuracy.
9.1.3 When expoing a .gc le with Lightburn, the current position needs to be selected as the bottom left corner to ensure accu-
rate positioning.
9.1.3 Enabling this function provides 2 features:
a) Auxilia material placement;
b) Positioning - when staing engraving, the laser will move to the crosshair position.
9.2 How to Calibrate Auxilia Positioning on the Display Screen:
9.1.4 This function is disabled by default for the auxilia positioning. A6 PRO does not have the auxilia positioning function,
while other models have it.
9.2.1 Choose "Red Light Positioning" and the laser crosshair light will turn on.
11
