AT
8
Enclosed tools
Hex wrench
Phillips screwdriver
Single side open end wrench
Assembly parts
Console x 1
Display Console x 1
Front armrest set x 1
Armrest cover x 2(L & R)
Upright safety cover x 2(L & R)
Accessory pack
Hardware parts box x 1
Safety key x 1
Power cable x 1
Line-level audio adapter x 1
Silicon oil x 1
Please contact the distributor or the Warranty card for technical support if any part is missing or you have any queson.
Please contact the distributor or the Warranty card for technical support if any part is missing or you have any queson.
Before Assembly
Single side open end wrench 17mm
Hex wrench-5mm
Hex wrench-6mm
Truss head Phillips screw
ST4.2*10
Start washer
Washer
Ø10
Buon Head Socket Bolt
M10*95-20
Nylon nuts
M10
Buon Head Socket Bolt
M8*34-12
Socket Head Cap Bolt
M6*16
Phillips screwdriver
