Attacus AT-200 - Assembly Procedure

AT
11
QtyDescriponParts TypeIllustraon
Step 1 of Assembly Procedure
A
B
C
1) Insert le inner cover of the le hand armrest in inner side of armrest
tube.
2) Remove and align le outer cover of the armrest as required.
3) Screw ght both the inner and outer covers of the armrest.
4) Repeat step 1~3 for the right hand armrest.
A
A
B
C
4
2
2
Le and right outer cover
Le and right inner cover
Cover
Cover
Screw Truss head Phillips screw (10L)
Hardware pack for step 1
Phillips screwdriver
