Motor
AT-LPW40WN: DC servo with Active Speed Stabilizati
on AT-LPW30TK: DC servo
Drive method
Belt drive
Speeds 33-1/3 RPM, 45 RPM
Turntable platte Aluminum Die Casting
Wow and flutter < 0.15 % WRMS (33 RPM) at 3 kHz
Signal-to-noise ratio > 60 dB
Output levels “PHONO” “LINE”
4.0 mV nominal at 1 kHz, 5 cm/sec 200 mV nominal at
1 kHz, 5 cm/sec
Phono Pre-amp gain 35 dB nominal, RIAA equalized
Tonearm specifications
Type
AT-LPW40WN: Static balanced straight carbon tonear
m AT-LPW30TK: Static balanced straight aluminium pi
pe tonearm
Effective length 223.6 mm
Overhang 18.6 mm
Maximum tracking error angle Less than 2.0°
