CHAPTER2 Setting up the Phone
C448HD C450HD | Users & Administrator's Manual
Rear View
Theportslocatedontherearofthephonearedescribedinthetable.
Figure 2-2: Rear View
Table 2-2: Rear View Description
# Label Description
1 Handsetjack,i.e.,portRJ-9,toconnectthehandset.
2 RJ-45porttoconnecttotheEthernetLANcablefortheLANconnection
(uplink-10/100/1000Mbps).Ifyou'reusingPoweroverEthernet(PoE),
powertothephoneissuppliedfromtheEthernetcable(drawspower
fromeitherasparelineorasignalline).
3 RJ-45porttoconnectthephonetoaPC(10/100/1000Mbpsdownlink).
4 12VDCpowerjackthatconnectstotheACpoweradapter.
5 Headsetjack,i.e.,RJ-9portthatconnectstoanexternalheadset.
- 16 -
