User's and Administrator's Manual 4. Teams Application
Version 0.314 33 450HD IP Phone
Figure 4-5: Shared Mode
4.1.1 Getting Acquainted with the Phone Screen
This section gets you acquainted with the phone’s user interface. The figure below shows the
screen when the phone is in idle state.
Figure 4-6: Phone Screen in Idle State - Calls
Use the table below as reference.
Table 4-1: Phone Screen in Idle State - Description
Item Description
The phone menu. Touch to open. The screen shown in Figure 4-7 below opens.
Calls
Touch the tab to open the Calls screen if it isn’t already (i.e., if the Meetings screen or
Voicemail screen is open). The screen shown in Figure 4-6 above opens.
Meetings Touch the tab to open the Meetings screen, shown in Figure 4-9 below opens.
Voicemail Touch the tab to open the Voicemail screen, shown in Figure 4-13 below opens.
