AudioCodes Mediant 800C SBC User Manual

7. Configuring AudioCodes Mediant 800C SBC
Mediant 800C with ZPLS
- 31 -
To configure a Proxy Address for SIP Trunk:
1. Open the Proxy Sets table (Setup menu > Signaling & Media tab > Core Entities folder > Proxy
Sets)
2. Click the Proxy Set SIPTrunk, and click the Proxy Address link located below the table; the
Proxy Address table opens.
3. Click +New, and configure the address of the Proxy Set according to the parameters described
in the table below:
Table 9: Configuration Proxy Address for SIP Trunk
Index
Proxy Address
Transport
Type
Proxy
Priority
Proxy Random
Weight
0
SIPTrunk.com:5060
(SIP Trunk IP / FQDN and port)
UDP
0
0
4. Click Apply.
