ASSEMBLY PARTS LIST
22
8200Q
8200Q-Assembly Bom-P1/2
R/N P/N PART NAME DESCRIPTION QTY
1 300-1028420000-1R Front Panel finish and anodized 1
2 215-1027410001R Button Cap painted 1
3 273-1028410000R Display Window 39*18*3.5mm 1
4 340-1027410000-2R Knob painted 4
5 307-1027410000R Knob Indicator painted 4
6 574-3000800011R Screw M3X8（BNI） 9
7 588-3000066037R Screw M3*6 15
8 215-1027410000R Power Button painted 1
9 305-1027410002R Main Switch Bracket painted 1
10 500-3050240300AR Nut M3 NI 6
11 263-0020100102R EVA LUMP
20*10*10mm，EVA， with single 3M
tape
1
12 534-3002061006R Screw M3*6 35
13 309-1028410002R Main Chassis painted and silkscreen 1
14 303-1028410000R Bottom Cover painted 1
15 226-0230191911R Feet black 4
16 319-1027410001R Side Panel sand blasting,anodized 2
17 801-0080030030R Ground Terminal Cap Φ8*Φ3*3mm 1
18 086-3811000000R Ground Terminal 1821T098-00 1
19 521-3005060500AR Washer M3*5*0.6,Cu 4
20 588-3000106037R Screw M3*10 6
21 231-2096000102R Rubber Washer Φ96*1mm,black 1
22 368-1028410000R Transformer Insulation Board black 1
23 215-1027410002MR Knob Cap Φ37*3.2mm 4
24 513-6412150780R Washer Φ6.4XΦ12X1.5,NI 1
25 500-6000000300R Nut M6 1
26 305-1028410000R Phono Bracket painted 1
27 226-0080031911R Feet Mainstay Φ8.0*Φ3.7*19.0/material is PP，black 1
28 302-1020410000R Top Cover sand blasting,anodized silver/black 1
29 534-3002100606R Screw M3*10 11
30 219-1028410000R Plastic Axes M3，ABS,black 1
31 553-0030040000R Screw M3*4 NI 1
32 331-1028420000R Knob Pole Φ6.0 L=192mm 1
33 336-1027410000R PCB Shield Cover nickel plated 1
34 415-1027410000R Shield Cover Sticker 104*60mm PVC 1
35 231-2013005012R PVC Washer Φ12.5*Φ4.5*0.1mm 5
36 205-1028410001R Raster Bracket Φ20*14.8mm、PP、black 1
37 231-1035020502R Nylon Washer 35*20*5mm 1
38 537-3001121006R Screw M3*12 2
To Next Page
