ELECTRONIC PARTS LIST
29
8200Q
8200Q-Electronic Bom-P6/6
R/N P/N PART/NAME DESCIPTION QYT LOCATION
131 088-1028414200R
8200 IR Receiver
Board
IR PCBA 1
132 053-1028411026R
8200Q IR PCB
ISS2
single
layer,54*28*1.6MM,FR4 20Z
blue
1
133 019-0011022000QR LED LED /RED 2 D200.D603
134 055-0305020344R FLAT WIRE
5P L=200MM UL2468
26AWG
1 CN1
135 052-2100000000R Infrared Receiver TSOP4836 1 IR
136 009-1040508110R Cap 100nF 50V 20% 1 C200
137 001-2200205010QR Resistor 22R 1/4W 1% 2 R203.204
138 001-2209205010QR Resistor 2R2 1/4W 1% 1 R603
139 001-8201205010QR Resistor 820R 1/4W 1% 2 R605.R201
140 223-0532220301R Plastic Post 3-3 2 D200,D603
141 018-1400550115-1R Transistor
BC550B NPN TO-92
FAIRCHILD
2 Q602.Q601
142 088-1028413800R
8200Q 12 Output
Board
Trigger12V OUT PCBA 1
143 006-1024102053QR Electrolytic Cap CAP 1000U 20% 35V RE2-F 1 C1
144 006-4711081643R Electrolytic Cap 470uF 25V 10% 10*20mm 1 C2
145 016-1041100001R
Polypropylene
Cap
0U1 5% 100V MKS2 wima
ph5mm
6C4-C8
146 067-1104148000R DIODE IN4148 1 D1
147 079-0501000000R
PCT
RESETTABLE
FUSES
RXE050 1 F1
148 001-0470308050R Resistor metal film 4.7Ω 2W J 1 R1
