ELECTRONIC PARTS LIST
28
8200Q
8200Q-Electronic Bom-P5/6
R/N P/N PART/NAME DESCIPTION QYT LOCATION
113 013-4730320504QR Cap
CAP 47000P 20% 100V X7R
CER
2
114 306-1027410003R Heat Sink anodized,black 2
115 306-1027410001R Heat Sink 1 anodized,black 4
116 537-3001060806R Screw M3*6 9 radiator1-4,radiator2-5
117 016-1001120001R
Polypropylene
Cap
10P 20% 100V P=5MM
L=11MM
10
C109-
111.115.116.209-
211.215.216
118 016-2201120001R
Polypropylene
Cap
22P 20% 100V P=5MM
L=13MM
2 C112.212
119 017-1276000000R IC
OPA2134PA 2X OP AMP
DIP 8PIN TI
2 IC101.IC201
120 057-2541201061R Single Header 6pin 2.54mm 2 6switch board
121 055-0305020344R Flat Wire
5P L=200MM UL2468
26AWG
1J1
122 056-4105221100R Connector DJ2802-05 2 EC860,SW862
123 020-2031321123HR
Motor
Potentiometer
20K ALPS RK16812MG
AX 916X
1VR100
124 001-2209205010QR Resistor 2R2 1/4W 1% 19
R112,113.212.213.51
3.514.517-519.540-
542.802,R972-979
125 306-1027410002R Heat Sink2 anodized, black 4 IC902.903,906,907
126 306-1119000002R Heat Sink TV5 1 IC908
127 089-1400000020-1R Six Way Switch
shaft length 20MM Φ6MM
SR10010F-0106-20ROA-C7-
NALPHA
2 SW861,VR1
128 051-1006334035-1R SOCKET
SOCKET 4WAY PHONO
GOLD PLATED T6288-
AABF up white/down red
5 J860-863.865
129 018-1400550115-1R Transistor
BC550B NPN TO-92
FAIRCHILD
22
416.420.500.501.702.
704-
706.710.900.Q102.10
4.106.111.112.116.20
2.204.206.211.212.21
6
130 018-1400560115-1R Transistor
BC560B PNP TO-92
FAIRCHILD
44
Q400-415.417-
419.421-
425.700.701.703.707.
709.Q100.101.105.11
0.113-
115.200.201.205.210.
213-215
To Next Page
