Audiolab 8200Q Service Manual

8200Q
8200Q-Electronic Bom-P4/6
27
ELECTRONIC PARTS LIST
R/N P/N PART/NAME DESCIPTION QYT LOCATION
94 019-0011022000QR LED LED/ RED 4
D100.D200.D704.D7
10
95 001-4703205010QR Resistor 47K 1/4W 1% 3 R420.R122.R222
96 016-4742100001R
Polypropylene
Cap
CAP 0U47 5% 250V
MKP4 WIMA 15PCM
2 C105.205
97 051-6100000001R SOCKET
2PIN RED /WHITE
T6302-AABF NE
1 J860/right
98 013-8220210505R Cap
8200P 5% 63V WIMA
PH5MM
2 C864.865
99 223-0414210201R Plastic Post
WHITE ABS PW-6
hight:2mm; inner
diameter:1.4mm; outside
diameter:4mm
2 X500
100 016-0141100001R
Polypropylene
Cap
0U01 5% 100V MKS2
WIMA PH5MM
8 C900-903.916-919
101 016-4740810001R
Polypropylene
Cap
0U47 10% 63V MKS2
WIMA PH5MM
15
C100.102.200.202.70
0.701.703-705.707-
711.933
102 016-3331100001R
Polypropylene
Cap
0U033 5% 100V MKS2
WIMA PH5MM
2 C702.706
103 016-4731100001R
Polypropylene
Cap
CAP 0U047 5% 100V
MKS2 PH5MM
2 C107.207
104 016-1041100001R
Polypropylene
Cap
0U1 5% 100V MKS2 wima
ph5mm
31
C502.504-507.511-
518.712-715.800-
803.910.911.926.927
.960-965
105 006-1004051133HR Electrolytic Cap
ELNA 10U 20% 16V RE3-
16V100ME3 5*11mm
3 C508.509.935
106 006-2204051153HR Electrolytic Cap
ELNA 22U 20% 35V RE3-
35V220ME3 5*11mm
9
C403.906.907.912.91
3.922.923.928.929
107 006-1014162552QR Electrolytic Cap
ELNA RE3-35V-101M F3
100UF 35V
14
C101.113.201.213.51
0.908.909.914.915.9
24.925.930.931.C400
108 006-1094051163HR Electrolytic Cap
1U0 20% 50V ELNA RE3-
50V010ME3 5*11mm
3 C401.402.503
109 006-1014081163HR Electrolytic Cap
ELNA100U 20% 50V RE3-
50V101MG3 8*11.5mm
1 C932
110 006-1034223543HR Electrolytic Cap
10000uf 20% 25V ELNA
LA5-25V103MS24
22*35mm
1 C934
111 017-1227000000R IC TL072BCN DIP8 ST 2 IC700.IC701
112 050-0400000000R Transistor Clip
DIMENSION 10*6MM
BLACK TR-1
5
IC900.902.904.906.9
08
