ELECTRONIC PARTS LIST
26
8200Q
8200Q-Electronic Bom-P3/6
R/N P/N PART/NAME DESCIPTION QYT LOCATION
64 008-4703002517QR Cap 0U047 +80/-20% 25V 5YF 9
C1.519-522.716-
718.866
65 017-4180000000QR IC
TL7705ACP 5V
SUPERVISOR DIP8 TI
1 IC503
66 017-4150000000QR IC
SN74HC00N 4X 2-IN NAND
14PIN TI
1 IC500
67 017-4160000000QR IC 74HC08 DIP14 TI 3 IC501,504,507`
68 017-4170000000QR IC
IC 74HC30N 8-IN NAND
philips
3 IC960-962
69 017-4140000000QR IC
74HC373N OCT3-ST
PHILIPS 20PIN
2 IC963.965
70 017-1380000000R IC
LM317T(1.5A) TO-220
（
ST
）
5 IC900.902.904.906.908
71 017-4590000000QR IC
IC NE5534P Ti OP-AMP
8PIN DIL
2 IC100.200
72 017-4600000000QR IC
IC HEF4093BP 14PIN DIL
Philips
1 IC508
73 017-4610000000QR IC
IC 74HC123N,652 philips
16PIN DIL
1 IC860
74 017-4620000000QR IC
74HC147N ENCODER
16PIN philips
1 IC964
75 017-4630000000QR IC L272M DIP8 ST 2 IC505.506
76 017-1390000000R IC
LM337T(1.5A) TO-220
Fairchild
4 IC901.903.905.907
77 024-1050101017R Relay TQ2-5V MATSUSHITA 17 RY860-875.884
78 024-1050101026QR Relay
G5V-1 5DC SIGNAL 1PCO
5V OMRON
8 RY876-883
79 067-1104148000R Diode IN4148 34 709.711.913-917
80 067-2204002000R Diode IN4002 12 D900-903.905-912
81 067-3307924900QR Zener Diode BZX79C 2V4 3 D421.701.707
82 067-3379629000QR Zener Diode
DIODE BZX79C 6V2 ZENER
TC
21 D400-417.419.420.770
83 029-0800000000QR Crystal
CER CSA400MG
RESONATOR
1 X500
84 089-1100000012QR Six Way Switch
SWITCH MOTORISED
SRBAA2603A
1 SW860
85 069-0700000000QR Grid Switch SG23FI 1 SW863
86 031-1100409110R Ceramic Fuse 3.6*10 F3.0A 250V 1 F900
87 001-0470308050R Resistor metal film 4.7Ω 2W J 2 R924.925
88 349-1006000011R Ground Barcket PCB-2 1 1321F
89 058-2842000000R IC Socket
DIP 28PIN pitch:2.54MM
round hole
1 IC502
90 013-1010310507R Cap FKP2 100pF 100V 5% 4 C103.108.203.208
91 018-0500369115R Effect Transistor
2SK369GR TO-92
TOSHIBA
4
Q103.Q203.
("matched pairs")
92 044-2910000000R Phone Jack AST-6.35-006B 1 J864
93 017-4200000000QR IC
IC PIC16C57-XT/P 8-BIT
28PIN MICROCHIP
1 IC502
To Next Page
