Audiolab 8200Q Service Manual

ELECTRONIC PARTS LIST
24
8200Q
8200Q-Electronic Bom-P1/6
R/N P/N PART/NAME DESCIPTION QYT LOCATION
1 062-1220000200R Mains Cable 2 meter American 1
2 041-1376000000QR Mains Switch
mains switch 2P SDDSA
3289A
1
3 071-1100000000R Tie Wrap 100MM YJ-100 12
4 044-1700000000QR Mains Inlet
mains inlet 2 POLE 2 fuse
locs
1
5 060-4180310312R
Double Insulated
Wire
UL1672 18 AWG
blue=310MM
1
6 060-4180310112R
Double Insulated
Wire
UL1672 18AWG BROMN
L=310MM
1
7 053-1374001104QR PCB Main Switch
PCB MAINS SWITCH 200
SERIES
1
8 085-0100000100R PVC Tube φ10mm 0.22
9 742-3000000000R Heat Sink Φ30 GRAY 0.06
10 742-3501000000R Heat Sink Φ35 BLACK 0.1
11 022-2000042368R Transformer 230V TOROID TI-103404 1
12 031-2200527121HR Fuse Tube
T1.6A/250V 213 5*20MM
LITTELFUSE
2
13 088-1028410000R 8200Q Mainboard PCBA 1
14 053-1028411000R
8200 Main Bare
PCB
two layer 2OZ
407.7*294.6*2.0MM blue /
white character
1
15 060-3282500400R Shield Cable two way 2547 #2*28AWG 0.2
16 001-4709205010QR Resistor 4R7 1/4W 1% 4 R904.905.914.915
17 001-1000205010QR Resistor 10R 1/4W 1% 1 R422
18 001-1001205010QR Resistor 100R 1/4W 1% 8
R704.716.800.902.90
3.912.913.923
19 001-1201205010QR Resistor 120R 1/4W 1% 8
R103.107.203.207.90
8.909.918.919
20 001-3001205010QR Resistor 300R 1/4W 1% 1 R922
21 001-3901205010QR Resistor 390R 1/4W 1% 4 R105.205.115.215
22 001-1002205010QR Resistor 1K 1/4W 1% 7 R501.866-871
23 001-1302205010QR Resistor 1K3 1/4W 1% 4 R906.907.916.917
24 001-1502205010QR Resistor 1K5 1/4W 1% 6
R705.717.900.901.91
0.911
25 001-2002205010QR Resistor 2K 1/4W 1% 2 R102.202
26 001-2202205010QR Resistor 2K2 1/4W 1% 9
R110.111.210.211.51
2.514.545.703.715
27 001-2702205010QR Resistor 2K7 1/4W 1% 2 R133.233
28 001-3002205010QR Resistor 3K 1/4W 1% 2 R707.720
29 001-3302205010QR Resistor 3K3 1/4W 1% 3 R415-417
30 001-4702205010QR Resistor 4K7 1/4W 1% 1 R500
31 001-5102205010QR Resistor 5K1 1/4W 1% 1 R423
