Audiolab 8200Q Service Manual

ELECTRONIC PARTS LIST
25
8200Q
8200Q-Electronic Bom-P2/6
R/N P/N PART/NAME DESCIPTION QYT LOCATION
32 001-5602205010QR Resistor 5K6 1/4W 1% 8 R515.516.530-535
33 001-1003205010QR Resistor 10K 1/4W 1% 57
546.701.713.801.960
-971.R106.206.400-
414.424.502-
511.520-
529.536.537.543
34 001-1503205010QR Resistor 15K 1/4W 1% 6
R101.125.126.201.22
5.226
35 001-2003205010QR Resistor 20K 1/4W 1% 2 R418.421
36 001-2203205010QR Resistor 22K 1/4W 1% 5
R104.108.204.208.53
8
37 001-3003205010QR Resistor 30K 1/4W 1% 4 R127.130.227.230
38 001-1004205010QR Resistor 100K 1/4W 1% 9
R709.710.721.722.80
3-805.920.921
39 001-1204205010QR Resistor 120K 1/4W 1% 6
R128.129.228.229.70
6.718
40 001-6804205010QR Resistor 680K 1/4W 1% 2 R711.723
41 001-8204205010QR Resistor 820K 1/4W 1% 2 R702.714
42 001-1005205010QR Resistor 1M 1/4W 1% 3 R539.708.719
43 001-6809205010QR Resistor 6R8 1/4W 1% 4 R547-550
44 001-1001308050QR Resistor 100R 2W 5% 2 R862.863
45 001-2200405010QR Resistor 22R 1/4W 1% 2 R120.220
46 001-4700405010QR Resistor 47R 0.25W 1% 4 R860.861.872.873
47 001-1201405010QR Resistor 120R 1/4W 1% 2 R131.231
48 001-3301405010QR Resistor 330R 0.25W 1% 4 R109.118.209.218
49 001-4701405010QR Resistor 470R 1/4W 1% 2 R117.217
50 001-6801405010QR Resistor 680R 0.25W 1% 2 R119.219
51 001-1002405010QR Resistor 1k0 1/4W 1% 2 R116.216
52 001-1202405010QR Resistor
1K21 1% 0.25W CMF55
T-9
2 R132.232
53 001-2202405010QR Resistor 2k2 1/4W 1% 2 R114.214
54 001-4702405010QR Resistor 4k7 0.25W 1% 2 R100.200
55 001-5602405010QR Resistor 5k6 0.25W 1% 2 R123.223
56 001-4703405010QR Resistor 47k 1/4W 1% 4 R121.122.221.222
57 001-2004405010QR Resistor 200k 1/4W 1% 2 R124.224
58 001-1001405010QR Resistor 100R 0.25W 1% 2 R134.234
59 001-0000105050QR Resistor 0R 1/4W 5% 5 WL860-863.900
60 006-6824253553QR Electrolytic Cap
CAP 6800U 20% 35V
LA5 ELNA
4 C904.905.920.921
61 016-3311132201QR
Polypropylene
Cap
330P 2.5% 100V FKP2
WIMA
8
C104.106.204.206.86
0-863
62 836-2200005005QR
Cap
（
Round
Type
）
22P 10% 50V
POLYPROPYLENE
2 C500.501
63 009-1031008110QR Cap 10NF/100V 20% 10 C719.720.936-943
