SPECIFICATION
2
8200Q
Inputs: Gain and Sensitivity
CD, TUNER, AUX, VIDEO, TAPE 1, TAPE 2: IMPEDANCE: 20kΩ
GAIN: Adjustable by 3dB steps 0 -15dB., corresponding to
SENSITIVITY (nom.): 100mV, 140mV, 200mV, 283mV, 400mV,
562mV
HEADPHONES: Gain adjustable 18dB - 33dB in 3dB steps
Signal To Noise Ratio (IHF,rel.0.5V
output)
Any input, any gain setting: 97dB
Headphones: 80 dB
Frequency Response
10 Hz-20 kHz ±0.2 dB: 1Hz-75 kHz -3 dB
Total Harmonic Distortion&Noise
Less than 0.007%ref 7.7V rms, 20Hz - 20kHz
Channel Balance
Within1dB
Channel Separation
Better than100 dB@1 kHz any input, any setting
Pre-amp Output
Max. Output >7.7 V RMS(20dBm); Output impedance 75Ω
Headphone Output
>7.7Vrms;100 (for headphones 8 -2 k impedance)
Record Output
VIDEO OUT, TAPE 1 OUT, TAPE 2 OUT:Gain 0 dB (x1); 100Ω
Muting
Attenuation>63 dB, controlled automatically
Operating Temperature Range
10-35 °C
Power Requirements(Depending on
Region)
50-60Hz 100V, 110-120V, and 220-230V models available
Maximum Power Consumption: 25 VA
Dimensions (W×H×D)
445×74×335mm- including feet, terminals and controls
445 ×64×302mm-excluding feet, terminals and controls
Weight
Net: 6 kg
Shipping: 7.3 kg
