2 LEDs for general diagnostics:
●
LED PWR (green) = Device ready for operation (power supply available)
●
LED ERROR (red) = Fault
2 status LEDs for the RS-485 interface:
●
LED RX (green) = Byte received on RS-485
●
LED STATUS (red) = Byte with incorrect bit(s) received on RS-485
3 status LEDs for each channel:
●
LED FAIL (red) = No or insufficient signal on RX
●
LED LIMIT (yellow) = Critical but still permissible receive level
●
LED Link/Act (green) = Good RX receive level. Data is received via the RS485 channel
Indications (LEDs)
Profibus DPSuitable bus systems
d-Light RS485 by eks Engel GmbH & Co. KG, www.eks-engel.de
Versions: 13-MM-ST, 13-MM-SC, 13-SM-ST, 13-SM-SC
● FO coupler for line or star topology:
- RS485/PBD-1KANAL-MM-ST-AC2 (AUMA article no.:
K007.920) / (EKS order no.: 01000 6221-FV)
- RS485/PBD-1KANAL-MM-SC-AC2 (AUMA article no.:
K007.921) / (EKS order no.: 01000 6223-FV)
- RS485/PBD-1KANAL-SM-ST-AC2 (AUMA article no.:
K007.922) / (EKS order no.: 01000 6231-L-FV)
- RS485/PBD-1KANAL-SM-SC-AC2 (AUMA article-no.:
K007.923) / (EKS order no.: 01000 6233-L-FV)
● FO coupler for loop topology:
- RS485/PBD-RING-MM-ST-AC2 (AUMA article-no.:
K007.924) / (EKS order no.: 01000 6371-FV)
- RS485/PBD-RING-MM-SC-AC2 (AUMA article no.:
K007.925) / (EKS order no.: 01000 6373-FV)
- RS485/PBD-RING-SM-ST-AC2 (AUMA article no.:
K007.926) / (EKS order no.: 01000 6381-L-FV)
- RS485/PBD-RING-SM-SC-AC2 (AUMA article no.:
K007.927) / (EKS order no.: 01000 6383-L-FV)
Required FO modules for the
master
14
Technical data
