2.4 FO terminal compartment: close
Figure 7: AUMA plug/socket connector SDE bus
[1] Cover
[2] Screws for cover
[3] O-ring
[4] Cable entries for fibre optic cables
[5] Blanking plugs
1. Clean sealing faces of cover [1] and housing.
2. Apply a thin film of non-acidic grease (e.g. petroleum jelly) to the sealing faces.
3. Check whether O-ring [3] is in good condition, correctly insert O-ring.
4. Fit cover [1] and fasten screws [2] evenly crosswise.
5. Fasten cable glands with the specified torque to ensure the required enclosure
protection.
