ExplanationSetting valueDefaultAccessParametersTypeNo.
Delay time for EMERGENCY
behaviour (EMERGENCY beha-
viour is only executed after the
delay time has expired).
Min = 0 [0.1 s]10R
Delay time
Mmss0116-12
Max = 1800 [0.1 s]
EMERGENCY position of multi-
port valve
Min = 0 [0.1 s]10R/W
EMCY position MPV
U1616-13
Max = 1800 [0.1 s]
Table 59: Timer function
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 20 bytes
Setting the operation mode:
Stepping mode in direction
CLOSE
0 : Off
0R/W
Step mode CLOSE
enum17-1
1 : Remote
2 : Local
3 : Remote and local
Setting the on time in direction
CLOSE
Min = 10 [0.1 s]50R/W
On time CLOSE
Mmss0117-2
Max = 1800 [0.1 s]
Setting the off time in direction
CLOSE
Min = 10 [0.1 s]50R/W
Off time CLOSE
Mmss0117-3
Max = 1800 [0.1 s]
Setting the start of stepping
mode in direction CLOSE
Min = 1 [0.1 %]1000R/W
Start stepping CLOSE
U1617-4
Max = 1000 [0.1 %]
Setting the end of stepping
mode in direction CLOSE
Min = 0 [0.1 %]0R/W
End stepping CLOSE
U1617-5
Max = 999 [0.1 %]
Setting the operation mode:
Stepping mode in direction
OPEN
0 : Off
0R/W
Step mode OPEN
enum17-6
1 : Remote
2 : Local
3 : Remote and local
Setting the on time in direction
OPEN
Min = 10 [0.1 s]50R/W
On time OPEN
Mmss0117-7
Max = 1000 [0.1 s]
Setting the off time in direction
OPEN
Min = 10 [0.1 s]50R/W
Off time OPEN
Mmss0117-8
Max = 1000 [0.1 s]
