AUMA AUMATIC AC 01.2 User Manual

ExplanationSetting valueDefaultAccessParametersTypeNo.
Setting the start of stepping
mode in direction OPEN
Min = 0 [0.1 %]0R/W
Start stepping OPEN
U1617-9
Max = 999 [0.1 %]
Setting the end of stepping
mode in direction OPEN
Min = 1 [0.1 %]1000R/W
End stepping OPEN
U1617-10
Max = 1000 [0.1 %]
Table 60: On time monitoring
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 6 bytes
Enable/disable on time monitor-
ing
0 : Function not active
0R/W
On time monitoring
enum23-1
1 : Function active
A warning is issued when ex-
ceeding the permissible running
time/h.
Min = 10 [min]15R/W
Perm. running time/h
U1623-2
Max = 60 [min]
A warning is issued when ex-
ceeding the permissible starts/h.
Min = 11200R/W
Permissible starts/h
U1623-3
Max = 1800
Table 61: Motion detector
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 12 bytes
With active motion detection the
verification is made whether the
actuator position changes due
to the manual operation within
the detection time dt by the
travel difference dx. Con-
sequently, a mechanical move-
ment can be detected at output
drive (signal: 'Handwheel opera-
tion')
0 : Function not active
1R/W
Motion detector
enum24-1
1 : Function active
Setting the detection time dt
Min = 10 [0.1 s]50R/W
Detect. time dt
Mmss0124-2
Max = 1800 [0.1 s]
Setting the travel difference dt
Min = 10 [0.1 %]10R/W
Travel diff. dx
U1624-3
Max = 100 [0.1 %]
Setting the detection time dt
Min = 1 [0.1 s]5R/W
Detect. time dt (MWG)
Mmss0124-4
Max = 20 [0.1 s]
70
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
