ExplanationSetting valueDefaultAccessParametersTypeNo.
Setting the travel difference dx
Min = 23R/W
Travel diff. dx (MWG)
U1624-5
Max = 20
The delay time defines the time
interval after terminating manual
operation until reset of the signal
'Handwheel operation'.
Min = 1 [0.001 s]6000R/W
Delay time
U1624-6
Max = 65535 [0.001 s]
Table 62: Operating time monitoring
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Operation mode of operating
time monitoring. The actuator
operating time can be made in
'Manual' operation mode.
0 : Off
0R/W
Operation mode
enum25-1
1 : Manual
Perm.op. time, manual
Min = 0 [0.1 s]9000R/W
Perm.op. time, manual
Mmss0125-2
Max = 36000 [0.1 s]
Table 63: Reaction monitoring
ErläuterungSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Operation mode of operating
time monitoring. The actuator
operating time can be made in
'Manual' operation mode.
0 : Off
0R/W
Operation mode
enum26-1
1 : Manual
Perm.op. time, manual
Min = 150 [0.1 s]150R/W
Perm.op. time, manual
U1626-2
Max = 3000 [0.1 s]
Table 64: Interlock
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 6 bytes
Operation mode of interlock
function
1 : Remote
3R/W
Oper. mode Interlock
enum27-1
2 : Local
3 : Remote and Local
Running direction in which the
interlock function is active
1 : OPEN
3R/W
Running dir. Interlock
enum27-2
2 : CLOSE
3 : OPEN and CLOSE
By-pass of interlock function in
operation mode EMERGENCY
0 : Off
0R/W
By-pass Interlock
enum27-3
1 : On
71
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Appendix
