ExplanationSetting valueDefaultAccessParametersTypeNo.
Hysteresis of limit switching
Min = 03R
Hysteresis limit
U1637-15
Max = 100
Adjust zero point for torque
Min = 200R
Torque adjust 0 point
U1637-16
Max = 20
Low limit setting (initial value)
for tripping torque CLOSE
Min = 0 [Nm]20R
Low limit T CLOSE
U1637-17
Max = 65535 [Nm]
High limit setting (final value) for
tripping torque CLOSE
Min = 0 [Nm]100R
High limit T CLOSE
U1637-18
Max = 65535 [Nm]
Low limit setting (initial value)
for tripping torque OPEN
Min = 0 [Nm]20R
Low limit T OPEN
U1637-19
Max = 65535 [Nm]
High limit setting (final value) for
tripping torque OPEN
Min = 0 [Nm]100R
High limit T OPEN
U1637-20
Max = 65535 [Nm]
Table 71: Potentiometer
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 8 bytes
Low limit setting for Uref (monit-
oring the 5 V reference voltage
for potentiometer)
Min = 0450R
Low limit Uref
U1638-1
Max = 1023
Low limit setting for Upote (limit
monitoring the potentiometer
wiper voltage)
Min = 077R
Low limit Upoti
U1638-2
Max = 1023
Low limit setting of potentiomet-
er signal range (monitoring the
potentiometer span)
Min = 0610R/W
Low limit Uspan
U1638-3
Max = 1023
Hysteresis of potentiometer
Min = 02R
Hysteresis
U1638-4
Max = 10
Table 72: Phase failure monitoring
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Adapt rotary direction for coun-
terclockwise rotating field
0 : Function not active
1R
Adapt rotary dir.
enum39-1
1 : Function active
Duration until phase monitoring
trips
Min = 20 [0.1 s]100R/W
Tripping time
U1639-2
Max = 3000 [0.1 s]
Table 73: Switchgear
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 2 bytes
Setting the reversing prevention
time
Min = 1 [0.1 s]3R
Revers. prevent. time
U1640-1
Max = 300 [0.1 s]
Table 74: Monitoring functions
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 18 bytes
Monitoring the heating system
in the AC
0 : Function not active
0R
Monitor heat. system
enum41-1
1 : Function active
Monitoring external 24 V DC
(external supply)
0 : Function not active
0R
Monitor 24 V DC ext.
enum41-2
1 : Function active
Monitoring 24 V DC for custom-
er (control voltage)
0 : Function not active
1R/W
Monitor 24 V DC cust.
enum41-3
1 : Function active
Monitoring 24 V AC0 : Function not active
1R
Monitor 24 V AC
enum41-4
1 : Function active
76
Actuator controls
Appendix AC 01.2/ACExC 01.2 Profibus DP
