AUMA AUMATIC AC 01.2 User Manual

ExplanationSetting valueDefaultAccessParametersTypeNo.
Monitoring internal 24 V DC0 : Function not active
1R
Monitor 24 V DC intern
enum41-5
1 : Function active
PTC tripping device monitoring0 : Function not active
0R
PTC trip. monit.
enum41-6
1 : Function active
RTC test0 : Function not active
1R
RTC test
enum41-7
1 : Function active
Monitoring time of heater resp.
of the heating system (warning
"Wrn heater" is issued if a fault
has continuously occurred dur-
ing this period)
Min = 600 [0.1 s]3000R
Heater monitor. time
U3241-8
Max = 36000 [0.1 s]
Table 75: Service interface
ErläuterungSetting valueDefaultAccessParametersTypeNo.
Data length = 22 bytes
Information for actuator identific-
ation within the plant (e.g. KKS
designation - Power Plant Clas-
sification system)
_GERAETE-
TAG_
R/W
Device tag
S2042-1
Settings for service operation
mode. Allows actuator control
via remote operation of service
interface depending on opera-
tion modes LOCAL or REMOTE.
0 : Control: LOCAL
0R/W
Service op. mode
enum42-2
1 : Control: LOC+REM
Table 76: Service functions
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 4 bytes
Creates new factory settings by
adopting the current settings
Min = 32768-1R
Create factory settings
I1645-1
Max = 32767
Reset current settings to factory
settings
Min = 32768-1R/W
Reset factory settings
I1645-2
Max = 32767
Table 77: General information
ExplanationSetting valueDefaultAccessParametersTypeNo.
Data length = 48 bytes
Torque fault OPEN active
Min = 0R
Torque fault OPEN
BOOL44-1
Max = 1
Torque fault CLOSE active
Min = 0R
Torque fault CLOSE
BOOL44-2
Max = 1
Selector switch1 : Local
R
Selector switch
enum44-3
2 : Off
3 : Remote
Actual position
Min = 0 [0.1 %]R
Actual position
U1644-4
Max = 1000 [0.1 %]
Torque
Min = 0 [0.1 %]R
Torque
U1644-5
Max = 1000 [0.1 %]
77
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Appendix
