AUMA AUMATIC ACExC 01.2 User Manual

DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
Output drive rotates without electric operation command.1(28) = "Bit: Running via
handw."
Bit: Handwheel oper.
5
No signal0
Output drive rotates due to operation command from
REMOTE.
1(27) = "Bit: Running RE-
MOTE"
Bit: Running REMOTE
6
No signal0
Output drive rotates due to operation command from
LOCAL.
1(26) = "Bit: Running LOC-
AL"
Bit: Running LOCAL
7
No signal0
Byte 7: Intermediate positions
Table 8: Byte 7: Intermediate positions
DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
Intermediate position 1 reached1(31) = "Bit: Intermediate
pos. 1"
Bit: Interm. pos. 1
0
No signal0
Intermediate position 2 reached1(32) = "Bit: Intermediate
pos. 2"
Bit: Interm. pos. 2
1
No signal0
Intermediate position 3 reached1(33) = "Bit: Intermediate
pos. 3"
Bit: Interm. pos. 3
2
No signal0
Intermediate position 4 reached1(34) = "Bit: Intermediate
pos. 4"
Bit: Interm. pos. 4
3
No signal0
Intermediate position 5 reached1(35) = "Bit: Intermediate
pos. 5"
Bit: Interm. pos. 5
4
No signal0
Intermediate position 6 reached1(36) = "Bit: Intermediate
pos. 6"
Bit: Interm. pos. 6
5
No signal0
Intermediate position 7 reached1(37) = "Bit: Intermediate
pos. 7"
Bit: Interm. pos. 7
6
No signal0
Intermediate position 8 reached1(38) = "Bit: Intermediate
pos. 8"
Bit: Interm. pos. 8
7
No signal0
Byte 8: Discrete inputs
Table 9: Byte 8: Discrete inputs
DescriptionValuePrm-Text-Def GSD fileDesignation
(process representation)
Bit
A high signal (+24 V DC) is present at digital input 1.1(39) = "Bit: Input DIN 1"
Bit: Input DIN 1
0
No signal0
A high signal (+24 V DC) is present at digital input 2.1(40) = "Bit: Input DIN 2"
Bit: Input DIN 2
1
No signal0
A high signal (+24 V DC) is present at digital input 3.1(41) = "Bit: Input DIN 3"
Bit: Input DIN 3
2
No signal0
A high signal (+24 V DC) is present at digital input 4.1(42) = "Bit: Input DIN 4"
Bit: Input DIN 4
3
No signal0
A high signal (+24 V DC) is present at digital input 5.1(43) = "Bit: Input DIN 5"
Bit: Input DIN 5
4
No signal0
A high signal (+24 V DC) is present at digital input 6.1(44) = "Bit: Input DIN 6"
Bit: Input DIN 6
5
No signal0
No signal (reserved)——6
No signal (reserved)——7
Byte 9 and byte 10: Input AIN 1
Byte 9 = high byte, byte 10 = low byte.
25
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Description of the data interface
