Byte 6: Intermediate positions
Table 29: Byte 6: Intermediate positions
DescriptionValueDesignation
(process representation)
Bit
Run to intermediate position 1.1
Fieldb. interm. pos. 1
0
No command0
Run to intermediate position 2.1
Fieldb. interm. pos. 2
1
No command0
Run to intermediate position 3.1
Fieldb. interm. pos. 3
2
No command0
Run to intermediate position 4.1
Fieldb. interm. pos. 4
3
No command0
Run to intermediate position 5.1
Fieldb. interm. pos. 5
4
No command0
Run to intermediate position 6.1
Fieldb. interm. pos. 6
5
No command0
Run to intermediate position 7.1
Fieldb. interm. pos. 7
6
No command0
Run to intermediate position 8.1
Fieldb. interm. pos. 8
7
No command0
Bits 0 – 7 allow the direct selection of 8 intermediate positions via fieldbus commands.
Hereby the selected intermediate position is approached directly, without stopping
in another intermediate position.
In this case, the actuator continues running until the selected intermediate position
has been reached. Example: Operation from position 5 to 7 without stopping at
position 6.
For further information, please refer to Manual (Operation and setting) AUMATIC
AC 01.2 Profibus DP.
If the multiport valve function is active (option), the entire byte 6 is used for coding
of multiport valve operation commands. Up to 12 positions can either be approached
selecting the shortest path, in clockwise direction (CW), or in counterclockwise
direction (CCW). Furthermore, the actuator can also be operated without any position
indications in clockwise or counterclockwise direction (CW or CCW).
Table 30: Operation commands via byte 6 for activated multiport valve function
Behaviour
≙ Operation direction/posi-
tion
Value
Position 1 is approached selecting the shortest
path
Position 1
0x01
Position 2 is approached selecting the shortest
path
Position 2
0x02
Position 3 is approached selecting the shortest
path
Position 3
0x04
Position 4 is approached selecting the shortest
path
Position 4
0x08
Position 5 is approached selecting the shortest
path
Position 5
0x10
Position 6 is approached selecting the shortest
path
Position 6
0x20
Position 7 is approached selecting the shortest
path
Position 7
0x40
Position 8 is approached selecting the shortest
path
Position 8
0x80
Position 9 is approached selecting the shortest
path
Position 9
0x81
37
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Description of the data interface
