Page #85 background imageLoading...
Page #85 background image
ExplanationSetting valueDefaultAccessParametersTypeNo.
The event filter for Events is
used to define which collective
signals are to be recorded into
the event report. As soon as the
memory is full, the oldest events
are overwritten.
0 : PVST status
93223R
Event filter for Events
enum61-5
1 : Warnings
2 : Fault
3 : Not ready REMOTE
4 : Device status
5 : Configuration warning
6 : Out of specification
7 : Function check
8 : Maintenance required
9 : Failure
10 : Configuration error
11 : Hydraulics error
12 : Wrong oper. com-
mand
13 : Internal error
14 : Internal warning
15 : Fieldbus status
16 : Hydraulics warning
17 : Failure (Cfg)
18 : Fault (Cfg)
19 : Warnings (Cfg)
20 : Not ready REMOTE
(Cfg)
21 : Config. error RE-
MOTE
22 : Collective signal 23
23 : SIL status
24 : Collective signal 25
25 : Collective signal 26
26 : Collective signal 27
27 : Collective signal 28
28 : FOC status
29 : Service 1
30 : Service 2
31 : Service 3
85
Actuator controls
AC 01.2/ACExC 01.2 Profibus DP Appendix
