5. Open Torque Trip
6. Close Torque Trip
7. Loss of Phase
8. TH-Trip
9. TOLR Trip
10. Control Supply Fail
11. Phase reversal
12. Jammed Valve
13. Power ON
14. Program Mode Indication
15. SP Reached ( via DAC/MODBUS)
16. Selector switch LOCAL
17. Selector switch OFF
18. Selector switch REMOTE
19. ESD Pressed
20. 24V DC Fail
21. Space Heater Fail
22. Running Open
23. Running Close
24. Remote Sel SW EN
25. PVST Fail
26. Intermediate Pos
27. 4-20mA Signal Fail
Note that the Additional Optional Relays and Additional Relays (Four Numbers) can be
configured for the same set of faults as shown in the flowchart below. The default settings
are off for all of them. These can be configured in Factory Settings in Diagnostic Mode
that will be discussed in section 4.2.
