5. The bottom row of the display indicates:
→
Save → continue with step 10
→
Edit → continue with step 6
6.
Press Edit.
➥
Display indicates: ▶ Observer (1)
7.
Select user level via Up ▲ Down ▼ resulting in the following significations:
→
black triangle: ▶ = current setting
→
white triangle: ▷ = selection (not saved yet)
8.
Press Ok.
➥
Display indicates: Password 0***
9.
Enter password (→ enter password).
➥
Display indicates: ▶ Language and Save (bottom row)
Language selection
10.
Select new language via Up ▲ Down ▼ resulting in the following significations:
→
black triangle: ▶ = current setting
→
white triangle: ▷ = selection (not saved yet)
11.
Confirm selection via Save.
➥
The display changes to the new language.The new language selection is saved.
