6.7.2. Parking frame
Figure 54: PAFEx 01.1 parking frame
Application
Parking frame for safe storage of a disconnected plug or cover.
For protection against touching the bare contacts and against environmental
influences.
Explosion hazard!
Risk of death or serious injury.
→
Prior to opening the device (removing the plug) ensure that the device is free
of gas and voltage!
→
Do NOT switch on voltage in potentially explosive atmospheres.
For PAFEx 01.1, separate operation instructions are available.
49
SAEx 07.2 – SAEx 16.2/SAREx 07.2 – SAREx 16.2 Control unit - electromechanical
ACExC 01.2 Intrusive Modbus RTU Electrical connection
