LOCAL MODE S0
OPEN
E2 100 %
FAULT IND.
Table 11: Description of the fault indications
RemedyDescriptionSignal
For further information, press
and go to
status indication
S1.
A fault has occurred,
FAULT IND.
For further information, press and go to
status indication
S2.
A warning has occurred,
WARNING IND.
For further information, press and go to
status indication
S1 (faults) or S2 (warnings).
Faults as well as warnings have occurred.
FAULT + WARNING
For further information, press and go to
status indication
S3 (cause for fault indicati-
ons).
The actuator cannot be operated from REMO-
TE.The actuator can only be operated via
the local controls.
NOT READY IND.
For further information, press and go to
status indication
S1 or S3.
Faults and the
NOT READY IND. signal
have occurred.
FLT + NR
For further information, press and go to
status indication
S2 or S3.
Warnings and the NOT READY IND. si-
gnal have occurred.
WRN + NR
For further information, press and go to
status indications
S1 to S3.
Faults, warnings, and the NOT READY
IND.
signal have occurred.
FLT + WRN + NR
10.2.2 Status indication S1 - faults
Faults are indicated within the status indication
S1:
FAULT IND. S1
NO FAULT
Table 12: Description of the fault indications
RemedyDescriptionSignal
No fault has occurred.
NO FAULT
For further information:
1.
Go to group
D0: Press C and hold it
down until diagnostic indication
D0 is
displayed.
2.
Go to diagnostic indication
D2: Press
twice.
Internal fault has occurred.
INTERNAL FAULT
Operation command in direction OPEN.Torque fault in direction CLOSE.
TORQUE FAULT (CLOSE)
Set selector switch to position Local control
(LOCAL) and reset fault indication via Reset
push button.
Or:
Perform reset command via fieldbus.
Operation command in direction CLOSE.Torque fault in direction OPEN.
TORQUE FAULT (OPEN)
Set selector switch to position Local control
(LOCAL) and reset fault indication via Reset
push button.
Or:
Perform reset command via fieldbus.
Test/connect phases.One phase is missing.
LOSS OF PHASE
57
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electromechanic
AC 01.1 Intrusive Modbus RTU Corrective action
