Technical data for limit and torque switches
2 x 10
6
startsMechanical lifetime
Silver plated contacts:
30 V AC/DCU min.
250 V AC/DCU max.
20 mAI min.
5 A at 250 V (resistive load)
3 A at 250 V (inductive load, cos phi = 0.6)
I max. AC current
0.4 A at 250 V (resistive load)
0.03 A at 250 V (inductive load, L/R = 3 µs)
7 A at 30 V (resistive load)
5 A at 30 V (inductive load, L/R = 3 µs)
I max. DC current
Gold plated contacts:
5 VU min.
30 VU max.
4 mAI min.
400 mAI max.
Technical data for blinker transmitter
10
7
startsMechanical lifetime
Silver plated contacts:
30 V AC/DCU min.
250 V AC/DCU max.
4 A at 250 V (resistive load)
4 A at 250 V (inductive load, cos phi = 0.8)
I max. AC current
0.4 A at 250 V (resistive load)
2 A at 30 V (resistive load)
I max. DC current
12.2 Features and functions of actuator controls
For mains voltage and mains frequency, refer to name plates at the controls and the motor
Permissible variation of the nominal voltage: ±10 %
Permissible variation of the mains frequency: ±5 %
Power supply, mains frequency
Motor current consumption: Refer to motor name plate
Current consumption of the controls depending on the mains voltage:
100 to 120 V AC = max. 650 mA
208 to 240 V AC = max. 325 mA
380 to 500 V AC = max. 190 mA
Current consumption
24 V DC +20 %/–15 %
Current consumption: Basic version approx. 200 mA, with options up to 500 mA
External supply of the electro-
nics (option)
The controls are designed for the rated power of the motor, refer to motor name plateRated power
Category III according to IEC 60364-4–443Overvoltage category
Standard:
Reversing contactors (mechanically and electrically interlocked) for motor power up to 1.5
kW, nominal motor current up to 9 A (OPEN-CLOSE duty) or 5.2 A (modulating duty)
Options:
●
Reversing contactors (mechanically and electrically interlocked) for actuators with 1-ph
DC motor 24 V, 48 V, 60 V, 110 V, 220 V (nominal current max. 25 A, start-up current
max. 70 A). Requires external supply of electronics with 24 V DC and thermal overload
relay
●
Thyristor unit (recommended for modulating actuators)
-
For motor power up to 1.5 kW, 500 V AC with internal fuses
Switchgear
2)
Via fieldbus interfaceControl
Via fieldbus interfaceOutput signals
2) The reversing contactors are designed for a lifetime of 2 million starts.
