Standard:
Modbus RTU interface without additional inputs
Options:
Additional inputs.The following version are available:
4 free 24 V DC inputs (current consumption: approx. ca. 5 mA/input) and 2 free 0/4 – 20
mA inputs. Signal transmission is made via fieldbus interface.
24 V DC control inputs OPEN – CLOSE – EMERGENY, or alternatively OPEN – STOP
– CLOSE (current consumption: approx. 5 mA/input). Selection of control mode via 24
V DC BUS/REMOTE input
24 V DC control inputs OPEN - CLOSE (current consumption: approx. 5 mA/input) and
0/4 – 20 mA input for position setpoint (positioner). Selection of control mode via 24 V
DC inputs BUS/REMOTE and MODE
24 V DC (115 V AC as option) control inputs OPEN - STOP - CLOSE - EMERGENCY
(current consumption: approx. 5mA/input) and 0/4 – 20 mA input for position setpoint
(positioner)
-
Selection of control mode via 24 V DC (optional 115 V AC) BUS/REMOTE and MODE
inputs
-
Status signals via 6 programmable output contacts, position feedback signal 0/4 –
20 mA
Fieldbus interface
Standard:
Auxiliary voltage 24 V DC, max. 100 mA for supply of the control inputs, galvanically isolated
from internal voltage supply
Option:
Auxiliary voltage 115 V AC, max. 30 mA to supply the control inputs
3)
, galvanically isolated
from internal voltage supply
Voltage output
Additional redundant Modbus RTU interfaceComponent redundancy (option)
AUMATIC is equipped with an additional redundant Modbus interface to form a redundant
loop when combined with the SIMA Master Station
Max. number of actuators equipped with AUMATIC actuator controls per redundant loop:
247 units. Max. possible cable length between the actuators equipped with AUMATIC
actuator controls without external repeater: 1,200 m
Max. possible total cable length per redundant loop: approx. 290 km
Redundancy in loop structure
(option)
Standard:
Selector switch LOCAL - OFF - REMOTE (lockable in all three positions)
Push buttons OPEN - STOP - CLOSE - RESET
5 indication lights:
-
End position CLOSED and running indication CLOSE (yellow), torque fault CLOSE
(red), motor protection tripped (red), torque fault OPEN (red), end position and running
indication OPEN (green)
LC display, illuminated
Programming interface (infra-red)
Options:
Bluetooth programming interface is equipped with a class II Bluetooth chip with a range
of up to 10 m.The interface supports the Bluetooth protocol SPP (Serial Port Profile).
Enabling the local controls using selector switch LOCAL - OFF - REMOTE via fieldbus
This way, actuator operation via push buttons of local controls can be either enabled or
disabled.
Special colours for the 5 indication lights:
-
End position CLOSED (green), torque fault CLOSE (blue), torque fault OPEN (yellow),
motor protection tripped (white), end position OPEN
Protection cover, lockable
Protection cover with indicator glass, lockable
Local controls
3) Not possible in combination with PTC tripping device
65
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electromechanic
AC 01.1 Intrusive Modbus RTU Technical data
