12. Technical data
Information The following technical data includes standard and optional features. For detailed
information on the customer-specific version, refer to the order-relevant data sheet.
This data sheet can be downloaded from the Internet at http://www.auma.com (in-
dication of commission number required).
12.1 Features and functions of actuator
SG: Short-time duty S2 - 15 min
SGR: Intermittent duty S4 - 25 %
Type of duty
1)
Refer to actuator name plateTorque range
Refer to actuator name plateOperating time for 90°
Standard:
3-ph AC asynchronous motor, type IM B9 according to IEC 60034 (SG and SGR)
Options:
●
1-ph AC motor, type IM B14 according to IEC 60034 (SG only)
●
DC shunt motor, type IM B14 according to IEC 60034 (SG only)
Motor
Standard: F, tropicalized
Option: H, tropicalized
Insulation class
Standard: Thermoswitches (NC)
Option: PTC thermistors (according to DIN 44082)
Motor protection
Ye sSelf-locking
Standard:
80° to 110° adjustable between min. and max. values
Option:
30° – 40°, 40° – 55°, 55° – 80°, 110° – 160°, 160° – 230° or 230° – 320°
Swing angle
Counter gear mechanism for end positions CLOSED and OPEN
Standard:
●
Single switch (1 NC and 1 NO) for each end position, switches not galvanically isolated
Options:
●
Tandem switches (2 NC and 2 NO) for each end position, switches galvanically isolated
●
Triple switches (3 NC and 3 NO) for each end position, switches galvanically isolated
●
Intermediate position switch (DUO limit switching), adjustable for any position
Limit switching
Torque switching adjustable for directions OPEN and CLOSE
Standard:
Single switch (1 NC and 1 NO) for each direction, switches not galvanically isolated
Option:
Tandem switches (2 NC and 2 NO) for each direction, switches galvanically isolated
Torque switching
Potentiometer or 0/4 – 20 mA (RWG)Position feedback signal, ana-
logue (option)
Continuous indication, adjustable indicator disc with symbols OPEN and CLOSEDMechanical position indicator
(option)
Blinker transmitterRunning indication (option)
Standard: Resistance type heater, 5 W, 24 V DC, (internal supply)Heater in switch compartment
Voltages: 110 – 220 V AC, 220 – 240 V AC or 400 V AC
Power: 12.5 W
Motor heater (option)
Manual drive for setting and emergency operation, handwheel does not rotate during electrical
operation.
Option: Handwheel lockable
Manual operation
AUMA plug/socket connector with screw-type connectionConnection to controls
Standard: Coupling without bore
Options: Machined coupling with bore and keyway, square bore or bore with two-flats accor-
ding to EN ISO 5211
Coupling
Dimensions according to EN ISO 5211Valve attachment
1) For nominal voltage and 20 °C ambient temperature and an average load with running torque or modulating torque according to sepa-
rate technical data.The type of duty must not be exceeded.
