AUMA SG 05.1-F05 User Manual

Information: Please state type and commission no. of the device (see name plate) when ordering spare parts.
Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts
AUMA from any liability. Delivered spare parts may slightly vary from the representation.
TypeDesignationNo.
Sub-assemblyHousing001.0
Sub-assemblyLocal controls002.0
Local controls board002.3
Sub-assemblyPower supply006.0
Bus-Platine008.1
Sub-assemblyLogic board009.0
Relay board011.1
Bus connection board050.1
Sub-assemblyCover500.0
Sub-assemblySocket carrier (complete with sockets)501.0
Sub-assemblyPin carrier without pins502.0
Sub-assemblySocket for controls503.0
Sub-assemblySocket for motor504.0
Sub-assemblyPin for controls505.0
Sub-assemblyPin for motor506.0
Sub-assemblyElectrical connection for bus without connection board (050.0)507.0
Sub-assemblyFrame507.1
Sub-assemblySwitchgear508.0
Padlock509.1
SetFuse kit510.0
SetSeal kitS
74
SG 05.1 – SG 12.1/SGR 05.1 – SGR 12.1 Control unit: electromechanic
Spare parts AC 01.1 Intrusive Modbus RTU
