DescriptionStatusLED
The module sends data via the
RS-485 interface
Illuminated in yellowTx
The module receives data via the
RS-485 interface
Illuminated in yellowRx
The fieldbus termination resistor
within the module is activated
Illuminated in yellowT
25
SIMA² Master Station
MODBUS RTU, MODBUS TCP/IP to DCS Indications
