11. Checklists
11.1. Commissioning checklist
Table 21: Checklist 1
⎕ ✓1. Actuator and actuator controls are correctly wired?
⎕ ✓2. Limit and torque switching set?
⎕ ✓3. Safety function (depending on the configuration) checked in accordance with the
proof test checklists?
⎕ Yes
⎕ No
4. Commissioning of basic settings (standard control) performed in accordance with
the operation instructions?
☒ ✓ = Done
11.2. Proof test checklists
If the proof test is performed according to proof test checklists, the pertaining
NOTICES contained in the <Tests and maintenance> chapter have to be observed.
11.2.1. Safe ESD safety operation (Safe OPENING/CLOSING) – irrespective of the selected control unit
Proof test checklist for version or configuration:
●
Safe ESD function “Safe CLOSING” (Safe ESD in direction CLOSE)
●
Safe ESD function “Safe OPENING” (Safe ESD in direction OPEN)
●
Irrespective of type of seating
Also valid for combination of Safe ESD with Safe STOP.
Table 22: Checklist 2
✎Configuration
Safe OPENING (Safe ESD in direction OPEN)
✎Configuration
Safe CLOSING (Safe ESD in direction CLOSE)
⎕ ✓1. Is actuator in mid-position or at sufficient distance
from the end positions?
⎕ ✓1. Is actuator in mid-position or at sufficient distance
from the end positions?
⎕ ✓2. Operation command in direction CLOSE executed?⎕ ✓2. Operation command in direction OPEN executed?
⎕ ✓
3. Safe ESDa and Safe ESDb input signals
set to 0 V (low)?
⎕ ✓
3. Safe ESDa and Safe ESDb input signals
set to 0 V (low)?
⎕ Yes
⎕ No
➥ Check actuator reaction:
Does actuator stop and run in direction OPEN up to
end position OPEN?
⎕ Yes
⎕ No
➥ Check actuator reaction:
Does actuator stop and run in direction CLOSE up to
end position CLOSED?
⎕ Yes
⎕ No
➥ Check SIL module signal behaviour:
No SIL fault signal?
SIL failure output (NC contact) = open)
⎕ Yes
⎕ No
➥ Check SIL module signal behaviour:
No SIL fault signal?
SIL failure output (NC contact) = open)
⎕ ✓
4. Safe ESDa and Safe ESDb input signals
set to +24 V DC (high)?
⎕ ✓
4. Safe ESDa and Safe ESDb input signals
set to +24 V DC (high)?
☒ ✓ = Executed
☒ Yes = Condition met
☒ No = Condition not met
If the answer to one of the questions is no, the safety instrumented system must be checked.
11.2.2. SIL fault signal “Actuator monitoring” – irrespective of the selected control unit
Proof test checklist for version or configuration:
●
Safe ESD function “Safe CLOSING” (Safe ESD in direction CLOSE)
●
Safe ESD function “Safe OPENING” (Safe ESD in direction OPEN)
●
Irrespective of type of seating
Also valid for combination of Safe ESD with Safe STOP.
46
Part-turn actuators
Checklists with AC 01.2-SIL/ACExC 01.2-SIL
