14.3.
Tightening torques f
or screws
T
able 38:
Tightening torques f
or screws
Tightening torque [Nm]
Threads
Strength class
A2-80/A4-80
A2-70/A4-70
10
7.4
M6
24
18
M8
48
36
M10
82
61
M12
200
150
M16
392
294
M20
1,057
1,015
M30
2,121
1,769
M36
98
SQEx 05.2
–
SQEx 14.2/SQREx 05.2
–
SQREx 14.2 Control unit:
electronic (MWG)
T
echnical data
A
CExC 01.2 Non-Intrusive Profibus DP
97
99
Table of Contents
Table of Contents
2
Safety Instructions
5
Prerequisites for the Safe Handling of the Product
5
Range of Application
6
Warnings and Notes
7
References and Symbols
7
Short Description
8
Name Plate
10
Transport and Storage
14
Transport
14
Storage
15
Assembly
17
Mounting Position
17
Handwheel Fitting
17
Mount Actuator to Valve
17
Overview on Coupling Variants
18
Mount Actuator (with Coupling)
18
Mounting Positions of Local Controls
21
Mounting Positions: Modify
21
Electrical Connection
22
Basic Information
22
Overview of AUMA Electrical Connections
24
KT/KM Electrical Connection
26
Terminal Compartment: Open
27
Cable Connection
28
Fieldbus Cables: Connect
30
Fieldbus Connection for Line Topology
30
Terminal Compartment: Close
32
KP/KPH Electrical Connection
33
Terminal Compartment: Open
34
Cable Connection
35
Fieldbus Cables: Connect
36
Terminal Compartment: Close
37
KES Electrical Connection
38
Terminal Compartment: Open
39
Cable Connection
40
Fieldbus Cables: Connect
41
Terminal Compartment: Close
42
External Earth Connection
42
Accessories for Electrical Connection
43
Actuator Controls on Wall Bracket
43
Parking Frame
44
Operation
45
Manual Operation
45
Manual Valve Operation
45
Motor Operation
45
Operating the Actuator from Local Controls
45
Actuator Operation from Remote
46
Menu Navigation Via Push Buttons (for Settings and Indications)
47
Menu Layout and Navigation
48
User Level, Password
49
Password Entry
49
Password Change
50
Timeout for Incorrect Password Entry
50
Language in the Display
51
Language Change
51
Indications
52
Indications During Commissioning
52
Indications in the Display
52
Feedback Signals from Actuator and Valve
53
Status Indications According to AUMA Classification
55
Status Indications According to NAMUR Recommendation
56
Indication Lights of Local Controls
58
Mechanical Position Indication (Self-Adjusting)
58
Mechanical Position Indication Via Indicator Mark (Not Self-Adjusting)
59
Signals (Output Signals)
60
Signals Via Modbus RTU
60
Status Signals Via Output Contacts (Digital Outputs)
60
Assignment of Outputs
60
Coding the Outputs
60
Analogue Signals (Analogue Outputs)
61
Commissioning (Basic Settings)
62
End Stops in Part-Turn Actuator
62
Set End Stop CLOSED
63
Set End Stop OPEN
63
Type of Seating: Set
64
Torque Switching: Set
65
Limit Switching: Set
67
Fieldbus Address (Slave Address): Set
68
Test Run
69
Direction of Rotation at Mechanical Position Indicator: Check
70
Limit Switching: Check
70
Commissioning (Settings in the Actuator)
72
Switch Compartment: Open/Close
73
Mechanical Position Indicator (Self-Adjusting)
73
Mechanical Position Indicator: Set
74
Gear Stage of the Reduction Gearing: Test/Set
74
Mechanical Position Indication Via Indicator Mark (Not Self-Adjusting)
75
Mechanical Position Indicator: Set
76
Gear Stage of the Reduction Gearing: Test/Set
76
Corrective Action
78
Faults During Commissioning
78
Fault Indications and Warning Indications
78
Fuses
82
Fuses Within the Actuator Controls
82
Fuse Replacement
83
Replace Fuses
83
Test/Replace Fuses
83
Motor Protection (Thermal Monitoring)
84
Servicing and Maintenance
85
Preventive Measures for Servicing and Safe Operation
85
Disconnection from the Mains
85
Disconnection from the Mains with KT/KM Electrical Connection
86
Disconnection from the Mains with KP/KPH and KES Electrical Connection
87
Maintenance
87
Disposal and Recycling
88
Technical Data
90
Technical Data Part-Turn Actuator
90
Technical Data Actuator Controls
92
Tightening Torques for Screws
98
Spare Parts
99
Part-Turn Actuators Sqex
99
Sqex 14.2/Sqrex 05.2
99
Sqrex 14.2 KT/KM
99
Actuator Controls Acexc 01.2 KT/KM
101
Actuator Controls Acexc 01.2 KP/KPH
103
Actuator Controls AUMATIC Acexc 01.2 KES
105
Index
109
