AUMA SQEx 05.2 User Manual

DP2 slave address M0295
Default value: 126
Setting range: 0 – 126
Information
Parameter DP2 slave address is only available if redundancy (option) is available.
Select main menu
1. Set selector switch to position 0 (OFF).
2.
Press push button C Setup and hold it down for approx. 3 seconds.
➥
Display goes to main menu and indicates: ▶ Display
Set fieldbus address
3. Select parameter either:
→
(by clicking through the menu)
→
or press and enter IDs M0098 or M0295 (direct selection)
➥
Display indicates: DP1 slave address
4.
Select via Up ▲ Down ▼:
→
▶ DP1 slave address
→
▶ DP2 slave address
➥
The black triangle ▶ indicates the current selection.
5.
Press Ok.
➥
Display shows the set address.
6. The bottom row of the display indicates:
→
Edit→ continue with step 7
→
Up ▲ Down ▼ → continue with step 11
7.
Press Edit.
➥
Display indicates: Observer (1)
8.
Select access level via Up ▲ Down ▼, resulting in the following significations:
→
black triangle: ▶ = current setting
→
white triangle: ▷ = selection (not saved yet)
Information: Required access level: Specialist (4) or higher
9.
Press Ok.
➥
Display indicates: Password 0***
10.
Enter password (→ enter password).
➥
Display shows the set address.
11.
Enter new address via Up ▲ Down ▼.
Information: The address range is displayed in round brackets on the screen.
12.
Confirm selection via Save.
➥
The setting for the Profibus address is complete.
10.6. Test run
Only perform test run only once all settings previously described have been
performed.
69
SQEx 05.2 – SQEx 14.2/SQREx 05.2 – SQREx 14.2 Control unit: electronic (MWG)
ACExC 01.2 Non-Intrusive Profibus DP Commissioning (basic settings)
